The Architecture, Engineering, and Construction (AEC) industry has witnessed groundbreaking evolutions.
Whether it is the Design phase, Planning, Construction, or post-construction Facility Management, the integration of technology spearheaded innovations at every stage. Among these technologies are the software applications, which make modern construction a breeze.
Revit and AutoCAD are two prominent and widely used ones. They now serve as the foundation of BIM-based workflows.
Both are products of Autodesk, the leading BIM software company globally.
While Revit is a BIM (Building Information Modelling) software, AutoCAD is a Computer-Aided Design (CAD) software. Even before BIM was introduced, CAD was the primary way to address the traditional and manual challenges.
This article will lay out a detailed comparison of both software applications, helping you understand their capabilities better.
Here’s how they entered the AEC industry and redefined construction processes.
The concept of CAD predates the software, and was there in the early 1960s.
Autodesk launched its first CAD software for personal computers in 1982 as AutoCAD. This move made the Computer-Aided Design accessible to architects, engineers, and designers. Soon, it became a standard industry choice for 2D designs, and with Autodesk’s further innovations, its capabilities evolved into 3D as well.
Mechanical and electrical engineers find AutoCAD a perfect fit; however, the software finds mainstream attention in the civil and architectural domains.
CAD dominated the industry for a long time, until the concept of BIM started making way in civil and architecture.
The concept of information modeling was receiving a positive reception, and this was further propelled by Revit’s entry in 1995. It added a layer of advancement, adding parametric value in information modeling.
This increased the accuracy of the modeling process, which is instrumental in the construction world.
Revit was part of the “Revit Technologies”, until Autodesk acquired it in 2002. This strategic acquisition pave way for the BIM software to be the most preferred option in the industry for the coming decades.
The continuous innovation from Autodesk has made Revit further advanced with multidisciplinary collaboration, advanced clash detection, and cloud collaboration capabilities.
We will gradually dive into more impressive features of Revit. Stay hooked.
Revit Architecture and AutoCAD are an instrumental part of modern construction. Both applications have their seperate capabilities, and here’s how they differ.
AutoCAD
AutoCAD finds extensive uses in the design drafting industry, where 2D and 3D drawings are required.
The tool provides impressive features for detailed drawings with precise dimensions. In the construction industry, it is primarily used to create blueprints, floor plans, and section drawings.
It holds powerful capabilities for creating mechanical, electrical, and plumbing drawings and coordinating them. It allows engineers to perform structural detailing and develop shop drawings for fabrication and installation.
Revit
The basic use of Revit is 3D modelling, but with a comprehensive set of capabilities.
The tool’s versatility allows even for simpler 2D draftings. However, the magic lies in the fact that Revit creates the 2D drawings automatically as the 3D model progresses.
Collaborating being instrumental in construction, Revit excels in creating, managing, and organizing asset data for better collaboration. It ensures data consistency across teams, reducing errors and rework.
The tool is also used for generating accurate cost estimations, sequencing construction phases to track progress, and validating spatial planning through Virtual Reality (VR) simulations.
AutoCAD comes with an easy-to-use interface for preparing detailed 2D and 3D drawings.
Working in AutoCAD simply means that professionals can manipulate lines and 2D shapes to adjust as per their requirements. It is the most renowned software among any architect graduate, which they learn to use in college and continue to use throughout their career.
For beginners without any knowledge of CAD, they will face moderate challenges initially using the software.
Within four to five weeks of consistent use, beginners can achieve functional productivity. However, if you are not a seasoned user, creating 3D drafting in AutoCAD is no easy feat. The problem arises when making changes to a 3D drawing, as geometry, plane, and components are not linked in AutoCAD.
This only works if the user is experienced working with complex models.
Revit delivers exceptional solutions to AEC professionals, revolutionizing workflows.
The software is a standalone for the application of BIM in building, houses, buildings, and great infrastructures. However, with the impressive capabilities it brings a steep learning curve for beginners.
For them, it will be a tough nut to crack before they are able to create intelligent data-rich models. Revits brings all the disciplines in a common plane, where they can collaborate on a single centralized model.
All these features add to the complexity of the tools, making the user interface difficult for beginners.
With consistent use, the tool becomes easy and a favorite one for your construction workflows. Coming back to comparing the two, it’s time to understand the set of plugins that these two can integrate for more efficient and productive workflows.
Autodesk has already integrated the necessary features for precise and accurate drawings and drafting.
However, it still offers a set of plugins aimed at increasing productivity. One of the widely used plugins is the Spatial Manager, which enables professionals to import, export, and manipulate spatial data in a CAD environment.
Another plugin used for plant and piping designs for complex process systems is CADWorx.
This one is popular among industrial designers for its in-built ability to keep designs compliant with industry standards, enabling the creation of 3D piping systems and generating automatic documentation from the 3D model.
Revit users are aware of the series of benefits that plugins offer.
Since the tool is complex in itself, the plugins help automate or sometimes simplify complex tasks. Plugins for Revit are a mix of various aspects of construction workflows. For example, plugins like pyRevit and Dynamo increase accuracy and productivity while creating 3D models.
Plugins like Lumion and Twinmotion are powerful visualization tools that help architects visualize the design while creating the 3D model.
Those are also used for rendering 3D models before creating 3D animations or simulations for a project showcase to stakeholders.
As powerful as both the tools are in their areas, they require well-equipped systems to perform well. Here’s what they require to perform at their full potential.
For mid-scale and large-scale organizations that deal with highly collaborative and complex infrastructure projects, these are the requirements:
Revit and AutoCAD both being from Autodesk support seamless interoperability.
Autodesk has also ensured that there is no data loss while transferring files from AutoCAD to Revit. BIM service providers on a global level like Pinnacle Infotech, use both of these as the basis of their workflows.
Without these two software applications, their operations are unimaginable.
But the question still remains,
Here’s what you need to know about these two.
As we saw earlier, both of the Autodesk products are premier solutions in their areas.
If your organization is focused on design and drafting services, which includes creating detailed plans, section drawings, etc, AutocAD is the best options.
Why is it so - Because AutoCAD gives you that flexibility to manipulate the geometry of the drawings with utmost ease. The software simply needs you to pull or push the size and dimensions of shapes to create specific details.
If your organization works on projects that require creating highly complex floor plans or section drawings, AutoCAD will be the best option for you.
However, if your organization looks forward to providing full-fledged BIM services, from design-drafting to 3D modelling, you need to adapt to a combined workflow.
You have to combine Revit's intelligent 3D modelling capabilities with AutoCAD’s design and drafting precision. With this combination, you will have the edge of interoperability between the two, which helps convert precise CAD designs to 3D models without any data loss.
Further, Revit will facilitate collaboration and better teamwork among disciplines, which is necessary for large-scale projects. Plus, frequent updates being common in such projects, Revit is a lifesaver.
An update to a model component is reflected across all views and other components connected to it automatically. This reduces complexity, allowing project teams to perform with increased productivity.
For advanced construction workflows, AutoCAD and Revit are used simultaneously for better outcomes.
So, it depends on your needs, either of them will suit.
Revit was originally introduced as Revit Architecture, which originally focused on architectural solutions. Gradually, as Autodesk came up with innovative updates, it became a comprehensive solution for the Architecture, Engineering, and Construction (AEC) industry.
Talking about the stability of Revit and AutoCAD, this depends on the following factors:
Workstations
The more powerful your workstations are, the better Revit and AutoCAD files will run smoothly.
However, if your organization develops highly complex 3D models for infrastructure projects, there might be latency even with powerful systems. It all boils down to the project scale and the value of deliverables you provide.
Organizations providing Digital Twin services need highly powerful custom-assembled systems for optimal operations.
Over-modeling
In case of specific projects, if there is a need for high-level detailing in early design stages, it can cause a slowdown.
Also, this can happen in case of poor optimization of workflows. Sometimes, downloading detailed Revit families, for example, HVAC families with units having internal coils, fan blades, brackets, etc.
These details multiply the file sizes and exert unnecessary load on the system, causing delays.
High number of XREFS
In AutoCAD, XREF files are used for coordination among disciplines.
These are external files linked with the main drawing, which might be structural and linked with the MEP drawing. In case of complex drawings, nested XREF files are used, which further adds to the processing power.
As the complexity of the file increases, users face latency issues, even if their systems are powerful.
While well-equipped workstations are critical, slowdowns depend upon the nature of the project to a great extent.
Revit can be used for highly complex modeling and visualization, and AutoCAD is widely used to prepare precise and detailed plans. With an array of official plugins, complexity may ease, but still, unexpected disputes may arise.
In such cases, users can seek help from a large community of modelers, architects, engineers, and other related construction professionals.
Community support Revit vs AutoCAD
Approved by Autodesk, there are several official forums where users can find answers to common software issues.
This is for both the platforms, and since these are used by a wide range of professionals, you will never be out of options. All of these forums are active and are crowded with industry professionals for varied experiences.
Revit Vs AutoCAD prices
While these two are the basic needs for design, drafting, and modeling, for startups and small firms, it will be a high price tag.
On the Autodesk official website, these are subscription-based for monthly, yearly, or 3-year plans. If you are looking to purchase either of the ones, you can visit here for detailed pricing and customer ratings.
Can Revit replace AutoCAD?
With further advancements in Revit, and as 0Revit can automatically generate drawings from 3D models, the replacement seems obvious.
However, this is not the case, as AutoCAD has a gigantic user base, and they are somehow attached to using it. The software finds extensive use for highly customizable 2D drawings and simpler projects.
The simplicity and flexibility that AutoCAD offers are the plus that will keep it competitive. Many organizations work on projects for technical plans, drafting works, where a full-fledged 3D model is not needed.
What has been seen in the industry is that both are used together, rather than one replacing the other. However, Revit has a pivotal role when it comes it complex infrastructure projects, where detailed 3D modeling and visualization are necessary for better project outcomes.
By now, we have covered the differences, advantages, and disadvantages of both software and how their combined use unlocks highly advanced and fruitful construction workflows.
Revit and AutoCAD continue to fuel advanced construction workflows as Autodesk brings further innovative updates.
Both tools come with their own set of advantages and innovative features. It all boils down to the project’s scale and complexity, which defines which one will serve better. However, AutoCAD alone is not enough for modern construction workflows. Hence, its combined use is the innovative approach we need to adapt for the future.
If you are completely new to the industry, learning AutoCAD first will introduce you to the simpler concepts before you move to Revit, which is more complex. However, if you aim to learn 3D modeling and visualizations, Revit is the one to choose first.
Out of several plugins, these are the key ones that are useful: Enscape, V-Ray, and Dynamo. These will help in real-time rendering and parametric modeling for more accurate project outcomes.
Yes, AutoCAD can be used for 3D modeling, but with limited capabilities. For more complex 3D modeling, Revit is the optimal choice and always a standard for industry professionals.
