BIM for Plant Engineering

With 30+ years of experience working in Plant Engineering projects, our team has a comprehensive understanding of Building Standards, Construction Practices, and Materials.

Combined with the excellent in-house training for our platform-independent departments enables us to offer industry-leading services in:

Plant 3D
CADWorx
Fabrication
Revit

BIM Services for Plant Engineering

Full Modeling and Design Workflow Management

Methodical approaches aligned with standard processes.
Identification of QC stages and development of a workflow process relevant to each project.

P&ID Creation & Validation

Creation, updating or replication of P&IDs with a large resource pool in conjunction with the design team to accelerate delivery times for your projects.
Validating model, P&ID, and Specifications to identify missing in-line equipment as well as incorrectly placed instruments.
Raising issues in a mark-up or tabled format as per your requirement.

Component Modelling & Specification Management

Generation of 3D model components from 2D data or add detail to existing 3D files.
We are proficient in modeling components required for your projects.

Drawings and Schedules Generation

Output documents that cater to all your needs – Isometrics, Orthographic, Bill of Materials, or any other required formats.
